ZED Box Orin NX 16GB

Order now. Ships in 2 weeks.

The ZED Box is a powerful AI gateway offering edge computing capabilities for autonomous robotics and smart video analytics. Powered by the latest NVIDIA Jetson Orin NX, it enables the deployment of state-of-the-art AI and 3D vision applications.

The ZED Box Orin™ series features an optional quad-port GMSL2 interface to streamline the utilization of the new ZED X GMSL2 cameras and can manage up to two ZED X together or four single GMSL2 cameras.

Processor Specifications

• NVIDIA® Jetson™ Orin NX 16GB module
• AI Performance: 100 TOPS
• GPU: 1,024-Core NVIDIA® Ampere™ architecture with 32 Tensor Cores @918MHz
• CPU : 8-Core Arm® Cortex®-A78AE @2GHz
• DL accelerator: 2xNVDLA v2 @614MHz
• Memory : 16GB  LPDDR5 102.4 GB/s

General Specifications

• 1x WiFi 6 connectivity included
• Power: PoE+ (25W) or DC-IN 5A 12-19V
• Aluminium case passively cooled
• Mounting options: 92x45mm mounting holes, wall (brackets provided) and DIN-rail mounting
• Weight: 0.7 kg (1.5lb)
• Dimensions: 118 x 92 x 71 mm (LxWxH) / 4.6 x 3.6 x 2.7 inches

Storage Options

• SSD 256GB or 1TB

GMSL2 Option

• Quad-port GMSL2 interface for 2x stereo cameras or 4x mono cameras (1 to 4 GMSL2 cable included)

GPS Option

•  GPS RTK U-blox ZED-F9P
• Supports GPS, GLONASS, Galileo, and BeiDou
